SINTESIS DAN KARAKTERISASI STRUKTUR PEROVSKITE BERBASIS LaMnO3 DENGAN SUBSTITUSI MULTI-KOMPONEN BERDASARKAN VARIASI KOMPOSISI

WULANDARI, TRI INTAN and Johan, Akmal and Setiawan, Jan (2025) SINTESIS DAN KARAKTERISASI STRUKTUR PEROVSKITE BERBASIS LaMnO3 DENGAN SUBSTITUSI MULTI-KOMPONEN BERDASARKAN VARIASI KOMPOSISI. Undergraduate thesis, Sriwijaya University.

Preview	Image RAMA_45201_08021282126031_cover.jpg - Accepted Version Available under License Creative Commons Public Domain Dedication. Download (451kB) | Preview
	Text RAMA_45201_08021282126031.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (4MB) | Request a copy
	Text RAMA_45201_08021282126031_TURNITIN.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (9MB) | Request a copy
	Text RAMA_45201_08021282126031_0021127309_8874700016_01_front_ref.pdf - Accepted Version Available under License Creative Commons Public Domain Dedication. Download (1MB)
	Text RAMA_45201_08021282126031_0021127309_8874700016_02.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (1MB) | Request a copy
	Text RAMA_45201_08021282126031_0021127309_8874700016_03.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (712kB) | Request a copy
	Text RAMA_45201_08021282126031_0021127309_8874700016_04.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (1MB) | Request a copy
	Text RAMA_45201_08021282126031_0021127309_8874700016_05.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (172kB) | Request a copy
	Text RAMA_45201_08021282126031_0021127309_8874700016_06_ref.pdf - Bibliography Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (315kB) | Request a copy
	Text RAMA_45201_08021282126031_0021127309_8874700016_07_lamp.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (1MB) | Request a copy

Abstract

This study aims to synthesize and characterize the crystal structure of LaMnO3-based perovskite materials with multi-component substitution to evaluate the effect of compositional variation on phase formation, lattice parameters, crystallite size, and lattice strain. The research was conducted at PRMM, BJ Habibie Science and Technology Area (KST), BRIN, Serpong, from late 2024 to early 2025 as part of a final project by a Physics student at Universitas Sriwijaya. Two composition variants, La0.7Sr0.3(Fe0.33Cu0.33Mn0.33)O3 and La0.7Sr0.3(Fe0.25Cu0.25Mn0.25Ni0.25)O3, were synthesized using the mechanical alloying method. Characterization was performed using X-Ray Diffraction (XRD), with diffraction patterns analyzed through Match! software, GSAS via Rietveld refinement, Williamson-Hall method, and VESTA for crystal structure visualization. The results showed that the Ni-free composition formed a single LaMnO3 with a cubic structure (Pm-3m), while the Ni-containing composition resulted in secondary phases, Cu6.8Fe1.2La6.4O20Sr1.6 (tetragonal, P4/mbm) and La2NiO4.24 (orthorhombic, Fmmm). The crystallite size of the Ni-containing material was smaller (53.33 nm) with higher lattice strain (0.002375), indicating greater structural distortion. Crystal structure visualization revealed atom distribution patterns consistent with these findings. Keywords: Perovskite, LaMnO3, Multi-Component Substitution, Mechanical Alloying, X-Ray Diffraction (XRD), Rietveld Refinement, Williamson-Hall, VESTA.

Item Type:	Thesis (Undergraduate)
Uncontrolled Keywords:	Kata kunci: LaMnO3, Substitusi Multi-Komponen, Mechanical Alloying, X-Ray Diffraction (XRD), Rietveld Refinement, Williamson-Hall, VESTA
Subjects:	Q Science > QC Physics > QC170-197 Atomic physics. Constitution and properties of matter. Including molecular physics, relativity, quantum theory, and > QC173.4.I57 Interfaces (Physical sciences) -- Mathematics. Crystallization -- Mathematical models. Mathematical physics.
Divisions:	08-Faculty of Mathematics and Natural Science > 45201-Physics (S1)
Depositing User:	Tri Intan Wulandari
Date Deposited:	21 May 2025 02:19
Last Modified:	21 May 2025 02:19
URI:	http://repository.unsri.ac.id/id/eprint/173404
