ADHA, WIJAYA KUSUMA and Bizzy, Irwin (2025) STUDI EKSPERIMENTAL PENDINGINAN PANEL SURYA TIPE MONOCRYSTALLINE 100 WP MENGGUNAKAN BEESWAX. Undergraduate thesis, Sriwijaya University.
![]() ![]() Preview |
RAMA_21201_03051282126056_cover.jpg - Cover Image Available under License Creative Commons Public Domain Dedication. Download (481kB) | Preview |
![]() |
Text
RAMA_21201_03051282126056.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (4MB) | Request a copy |
![]() |
Text
RAMA_21201_03051282126056_TURNITIN.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (6MB) | Request a copy |
![]() |
Text
RAMA_21201_03051282126056_0028086015_01_front_ref.pdf - Accepted Version Available under License Creative Commons Public Domain Dedication. Download (1MB) |
![]() |
Text
RAMA_21201_03051282126056_0028086015_02.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (731kB) | Request a copy |
![]() |
Text
RAMA_21201_03051282126056_0028086015_03.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (450kB) | Request a copy |
![]() |
Text
RAMA_21201_03051282126056_0028086015_04.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (922kB) | Request a copy |
![]() |
Text
RAMA_21201_03051282126056_0028086015_05.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (12kB) | Request a copy |
![]() |
Text
RAMA_21201_03051282126056_0028086015_06_ref.pdf - Bibliography Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (107kB) | Request a copy |
![]() |
Text
RAMA_21201_03051282126056_0028086015_07_lamp.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (2MB) | Request a copy |
Abstract
One of the major obstacles faced during the operation of solar panels is overheating due to excessive radiation from the sun and high ambient temperature. To overcome the temperature rise of solar panels and increase their efficiency, cooling of solar panels is required. The use of Phase Change Material (PCM) in the form of beeswax as a passive cooling method for solar panels can be implemented to absorb heat and store heat so that there is a decrease in the surface temperature of solar panels. In this research, the solar panel used is a monocrystalline type with a length of 1020 mm and a width of 620 mm, with a maximum output power of 100 W. During the research using the same two types of solar panels were evaluated, one using phase change material in the form of beeswax and without beeswax. The solar panels were installed at a 15° inclination. The study started at 10:00 am and ended at 4:00 pm for three days. The results showed that the surface temperature of solar panels using beeswax for three days was between 61°C-72°C and solar panels without beeswax was between 50°C-55°C. The use of beeswax has not been effective in reducing the temperature of solar panels due to the small gap between the back surface of the solar panel and the beeswax radiator which acts as a thermal insulator and the lack of thickness of the beeswax. However, solar panels using beeswax experienced an average increase in solar panel efficiency of 8.12%
Item Type: | Thesis (Undergraduate) |
---|---|
Uncontrolled Keywords: | Solar Panel, Beeswax, Efisiensi, Phase Change Material |
Subjects: | T Technology > TJ Mechanical engineering and machinery > TJ807-830 Renewable energy sources > TJ808.2.S6625 Renewable energy sources--Electric power production |
Divisions: | 03-Faculty of Engineering > 21201-Mechanical Engineering (S1) |
Depositing User: | Wijaya Kusuma Adha |
Date Deposited: | 23 May 2025 01:40 |
Last Modified: | 23 May 2025 01:40 |
URI: | http://repository.unsri.ac.id/id/eprint/173735 |
