RANCANG BANGUN PEMBANGKIT LISTRIK BERBASIS THERMOELECTRIC GENERATOR YANG MEMANFAATKAN PANAS MATAHARI DENGAN PENAMBAHAN LENSA FRESNEL SERTA HEATSINK YANG MENGGUNAKAN WATER COOLANT SEBAGAI MEDIA PENDINGIN

HASANA, AYU USWATUN and Caroline, Caroline (2025) RANCANG BANGUN PEMBANGKIT LISTRIK BERBASIS THERMOELECTRIC GENERATOR YANG MEMANFAATKAN PANAS MATAHARI DENGAN PENAMBAHAN LENSA FRESNEL SERTA HEATSINK YANG MENGGUNAKAN WATER COOLANT SEBAGAI MEDIA PENDINGIN. Undergraduate thesis, Sriwijaya University.

Preview	Image RAMA_20201_03041182126018_cover.jpg - Accepted Version Available under License Creative Commons Public Domain Dedication. Download (500kB) | Preview
	Text RAMA_20201_03041182126018.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (14MB) | Request a copy
	Text RAMA_20201_03041182126018_TURNITIN.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (5MB) | Request a copy
	Text RAMA_20201_03041182126018_0025017706_01_front_ref.pdf - Accepted Version Available under License Creative Commons Public Domain Dedication. Download (4MB)
	Text RAMA_20201_03041182126018_0025017706_02.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (795kB) | Request a copy
	Text RAMA_20201_03041182126018_0025017706_03.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (687kB) | Request a copy
	Text RAMA_20201_03041182126018_0025017706_04.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (600kB) | Request a copy
	Text RAMA_20201_03041182126018_0025017706_05.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (241kB) | Request a copy
	Text RAMA_20201_03041182126018_0025017706_06_ref.pdf - Bibliography Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (212kB) | Request a copy
	Text RAMA_20201_03041182126018_0025017706_07_lamp.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (8MB) | Request a copy

Abstract

Thermoelectric generator (TEG) is a technology that converts heat into electricity and has the potential to serve as an environmentally friendly power source. This study designed a prototype power generator based on six SP1848-27145 SA type TEG modules arranged in series. The heat source comes from solar radiation focused by a Fresnel lens onto a black-painted aluminum plate. The cold side uses a heatsink submerged in water coolant. Between the hot and cold sides, a thermal insulator made of bubble laminated foil is installed to minimize heat transfer. Test results show that the temperature difference between the hot and cold sides affects the electrical output. At the highest temperature difference of 19,7°C, the system produced a voltage of 2,04 V, a current of 0,564 mA, and a power output of 0,001264 W. Conversely, at the lowest temperature difference of 12,2°C, the output dropped to 1,26 V, 0,044 mA, and 0,000075 W. These results indicate that the developed TEG system has potential as a simple electricity generator based on renewable energy.

Item Type:	Thesis (Undergraduate)
Uncontrolled Keywords:	Thermoelectric generator, Solar Energy, Fresnel Lens, Thermal Insulation, Water Coolant, Temperature Difference
Subjects:	T Technology > TK Electrical engineering. Electronics Nuclear engineering > TK1001-1841 Production of electric energy or power. Powerplants. Central stations > TK1041.B68 1. Cogeneration of electric power and heat. 2. Combined cycle power plants. T Technology > TK Electrical engineering. Electronics Nuclear engineering > TK4001-4102 Applications of electric power
Divisions:	03-Faculty of Engineering > 20201-Electrical Engineering (S1)
Depositing User:	Ayu Uswatun Hasana
Date Deposited:	04 Jun 2025 01:21
Last Modified:	04 Jun 2025 01:21
URI:	http://repository.unsri.ac.id/id/eprint/175103
