ANALISIS KOORDINASI SISTEM PROTEKSI OVERCURRENT RELAY DAN RECLOSER PADA PENYULANG DISTRIBUSI 20KV MENGGUNAKAN METODE FAILURE MODE AND EFFECT ANALYSIS (FMEA)

KAMILA, IRTIZA SYIFA and Herlina, Herlina (2025) ANALISIS KOORDINASI SISTEM PROTEKSI OVERCURRENT RELAY DAN RECLOSER PADA PENYULANG DISTRIBUSI 20KV MENGGUNAKAN METODE FAILURE MODE AND EFFECT ANALYSIS (FMEA). Undergraduate thesis, Sriwijaya University.

Preview	Image RAMA_20201_03041382126116_COVER.jpg - Accepted Version Available under License Creative Commons Public Domain Dedication. Download (281kB) | Preview
	Text RAMA_20201_03041382126116.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (7MB) | Request a copy
	Text RAMA_20201_03041382126116_TURNITIN.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (14MB) | Request a copy
	Text RAMA_20201_03041382126116_0007078005_01_front_ref.pdf - Accepted Version Available under License Creative Commons Public Domain Dedication. Download (2MB)
	Text RAMA_20201_03041382126116_0007078005_02.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (846kB) | Request a copy
	Text RAMA_20201_03041382126116_0007078005_03.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (420kB) | Request a copy
	Text RAMA_20201_03041382126116_0007078005_04.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (2MB) | Request a copy
	Text RAMA_20201_03041382126116_0007078005_05.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (327kB) | Request a copy
	Text RAMA_20201_03041382126116_0007078005_06_ref.pdf - Bibliography Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (232kB) | Request a copy
	Text RAMA_20201_03041382126116_0007078005_07_lamp.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (2MB) | Request a copy

Abstract

The 20 kV distribution system at the Keramasan Substation, especially at the Bali feeder, often experiences short circuit disturbances due to external factors, which can cause blackouts and reduce the reliability of the feeder. Therefore, the author discusses the coordination of the overcurrent relay (OCR) and recloser on the Bali feeder connected to the 70/20 kV Transformer II of the Keramasan Substation using the Failure Mode and Effect Analysis (FMEA) method to analyze the reliability of the feeder. After mathematical calculations, the three-phase short circuit value was obtained as 2976.0323 A, the two-phase short circuit was 2578.6987 A and the single-phase short circuit current was 1564.1639 A. On the incoming side of the Overcurrent relay, the working time was 0.69866 seconds, on the outgoing side it was 0.299 seconds, the working time on the highset recloser was 0.153 and the lowset was 0.1227. The use of FMEA method to identify potential failures obtained the results of the reliability analysis of the Bali feeder with a SAIFI reliability index of 1.64395, SAIDI of 1.677574297 and CAIDI of 1.020453. When compared with SPLN, the value of the Bali feeder reliability index is included in the unreliable category.

Item Type:	Thesis (Undergraduate)
Uncontrolled Keywords:	Protection coordination, recloser, overcurrent relay, Reliability Index, FMEA method
Subjects:	T Technology > TK Electrical engineering. Electronics Nuclear engineering > TK3001-3521 Distribution or transmission of electric power
Divisions:	03-Faculty of Engineering > 20201-Electrical Engineering (S1)
Depositing User:	Irtiza Syifa Kamila
Date Deposited:	20 Jun 2025 06:58
Last Modified:	20 Jun 2025 06:58
