ANALISIS PENGARUH PRESSURE PADA GAS SF6 SEBAGAI MEDIA ISOLASI TERHADAP KINERJA PEMUTUS TENAGA (PMT) DI GARDU INDUK SUNGAI JUARO

ALIFA, MISE HANI and Herlina, Herlina (2025) ANALISIS PENGARUH PRESSURE PADA GAS SF6 SEBAGAI MEDIA ISOLASI TERHADAP KINERJA PEMUTUS TENAGA (PMT) DI GARDU INDUK SUNGAI JUARO. Undergraduate thesis, Sriwijaya University.

Preview	Image RAMA_20201_03041382126101_COVER.jpg - Accepted Version Available under License Creative Commons Public Domain Dedication. Download (439kB) | Preview
	Text RAMA_20201_03041382126101.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (4MB) | Request a copy
	Text RAMA_20201_03041382126101_TURNITIN.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (11MB) | Request a copy
	Text RAMA_20201_03041382126101_0007078005_01_front_ref.pdf - Accepted Version Available under License Creative Commons Public Domain Dedication. Download (3MB)
	Text RAMA_20201_03041382126101_0007078005_02.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (617kB) | Request a copy
	Text RAMA_20201_03041382126101_0007078005_03.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (335kB) | Request a copy
	Text RAMA_20201_03041382126101_0007078005_04.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (1MB) | Request a copy
	Text RAMA_20201_03041382126101_0007078005_05.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (214kB) | Request a copy
	Text RAMA_20201_03041382126101_0007078005_06_ref.pdf - Bibliography Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (212kB) | Request a copy
	Text RAMA_20201_03041382126101_0007078005_07_lamp.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (771kB) | Request a copy

Abstract

SF₆ gas (sulfur hexafluoride) is widely used as an insulating and arcquenching medium in high-voltage equipment such as Circuit Breakers (CB) due to its superior dielectric properties. However, the quality of this gas can deteriorate due to environmental and operational factors. This study aims to evaluate the quality of SF₆ gas in CBs based on three main parameters: pressure, dew point, and moisture content. Pressure is measured using a pressure gauge and absolute pressure, then compared with manufacturer standards. Dew point and moisture content are measured using a moisture analyzer in accordance with IEEE 1125 standards, with a maximum limit of 200 ppmv. The analysis is conducted using the FMEA method to identify potential failures such as leakage and high humidity, as well as ANOVA to test the differences between CB bays. ANOVA results of 99.357, 691.343, and 128.481 with an F-table value of 3.106 indicate that the null hypothesis is rejected for all parameters, indicating significant differences between CBs, especially in gas pressure. Some extreme values, such as a pressure of 4 bar,are suspected to be caused by weather fluctuations and microscopic leaks. FMEA recommends visual inspections, leakage evaluations, and routine monitoring. The dew point and moisture content results show significant differences but remain within safe limits. This study emphasizes the importance of regular monitoring and maintenance to ensure system reliability at the Sungai Juaro Substation. Keyword: SF6 gas, Circuit breaker, Pressure, FMEA, ANOVA

Item Type:	Thesis (Undergraduate)
Uncontrolled Keywords:	Keyword: SF6 gas, Circuit breaker, Pressure, FMEA, ANOVA
Subjects:	T Technology > TK Electrical engineering. Electronics Nuclear engineering > TK3001-3521 Distribution or transmission of electric power
Divisions:	03-Faculty of Engineering > 20201-Electrical Engineering (S1)
Depositing User:	Mise Hani Alifa
Date Deposited:	23 Jun 2025 02:56
Last Modified:	23 Jun 2025 02:56
URI:	http://repository.unsri.ac.id/id/eprint/175848
