IMPLEMENTASI PYTHON PADA SISTEM OBSERVASI KUALITAS DAYA LISTRIK

HANIF, FARHAN and Sidik, Muhammad Abu Bakar (2025) IMPLEMENTASI PYTHON PADA SISTEM OBSERVASI KUALITAS DAYA LISTRIK. Undergraduate thesis, Sriwijaya University.

	Image RAMA_20201_03041282126069_cover.jpeg - Accepted Version Available under License Creative Commons Public Domain Dedication. Download (358kB)
	Text RAMA_20201_03041282126069.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (14MB) | Request a copy
	Text RAMA_20201_03041282126069_TURNITIN.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (8MB) | Request a copy
	Text RAMA_20201_03041282126069_0014087102_01_front_ref.pdf - Accepted Version Available under License Creative Commons Public Domain Dedication. Download (4MB)
	Text RAMA_20201_03041282126069_0014087102_02.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (629kB) | Request a copy
	Text RAMA_20201_03041282126069_0014087102_03.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (575kB) | Request a copy
	Text RAMA_20201_03041282126069_0014087102_04.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (1MB) | Request a copy
	Text RAMA_20201_03041282126069_0014087102_05.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (215kB) | Request a copy
	Text RAMA_20201_03041282126069_0014087102_06_ref.pdf - Bibliography Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (188kB) | Request a copy
	Text RAMA_20201_03041282126069_0014087102_07_lamp.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (439kB) | Request a copy

Abstract

The increasing use of sensitive electronic devices has raised concerns about electrical power quality, which is often affected by disturbances such as harmonics, voltage fluctuations, and low power factor. These disturbances can degrade equipment performance, cause damage, and increase operational costs. This research aims to develop a prototype single-phase electrical power quality observation system using Python, capable of monitoring disturbance parameters based on IEEE standards. The developed system, named PQlyz, integrates hardware such as the Picoscope 5000 Series, Differential Probe, and Ampere Clamp for data acquisition. It then processes this data using Python libraries like Pandas, NumPy, SciPy (for Fast Fourier Transform), Matplotlib (for visualization), and PyQt5 (for the graphical user interface). The data is analyzed to calculate RMS voltage and current, active, reactive, and apparent power, power factor, voltage fluctuations, Total Harmonic Distortion (THD), individual harmonics (H1, H3, H5, etc.), and detect sags, swells, and interruptions. The analysis results are presented in numerical tables and graphical visualizations. Prototype testing demonstrates that the application consistently measures key power quality parameters, provides accurate data, and features a user-friendly interface. However, the current system operates offline and is limited to single-phase systems. The contribution of this research is expected to serve as a foundation for developing more advanced, efficient, and economical power quality observation systems in the future, particularly with real-time monitoring capabilities and three-phase functionality.

Item Type:	Thesis (Undergraduate)
Uncontrolled Keywords:	Prototipe Kualitas Daya, GUI
Subjects:	T Technology > TK Electrical engineering. Electronics Nuclear engineering > TK4001-4102 Applications of electric power
Divisions:	03-Faculty of Engineering > 20201-Electrical Engineering (S1)
Depositing User:	Farhan Hanif
Date Deposited:	23 Jul 2025 02:55
Last Modified:	23 Jul 2025 02:55
URI:	http://repository.unsri.ac.id/id/eprint/179860
