PERENCANAAN KONVERSI METODE SUCKER ROD PUMP MENJADI METODE ELECTRICAL SUBMERSIBLE PUMP PADA SUMUR RAA-137 DI PT PERTAMINA HULU ROKAN REGION 1 ZONA 4, PRABUMULIH FIELD

RASYIDIN, MUHAMMAD and Waristian, Harry and Prabu, Ubaidillah Anwar (2025) PERENCANAAN KONVERSI METODE SUCKER ROD PUMP MENJADI METODE ELECTRICAL SUBMERSIBLE PUMP PADA SUMUR RAA-137 DI PT PERTAMINA HULU ROKAN REGION 1 ZONA 4, PRABUMULIH FIELD. Undergraduate thesis, Sriwijaya University.

	Image RAMA_31201_03021382126091_cover.jpg - Accepted Version Available under License Creative Commons Public Domain Dedication. Download (219kB)
	Text RAMA_31201_03021382126091.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (11MB) | Request a copy
	Text RAMA_31201_03021382126091_TURNITIN.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (17MB) | Request a copy
	Text RAMA_31201_03021382126091_0014058902_9990445896_01_front_ref.pdf - Accepted Version Available under License Creative Commons Public Domain Dedication. Download (3MB)
	Text RAMA_31201_03021382126091_0014058902_9990445896_02.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (1MB) | Request a copy
	Text RAMA_31201_03021382126091_0014058902_9990445896_03.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (858kB) | Request a copy
	Text RAMA_31201_03021382126091_0014058902_9990445896_04.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (544kB) | Request a copy
	Text RAMA_31201_03021382126091_0014058902_9990445896_05.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (180kB) | Request a copy
	Text RAMA_31201_03021382126091_0014058902_9990445896_06_ref.pdf - Bibliography Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (223kB) | Request a copy
	Text RAMA_31201_03021382126091_0014058902_9990445896_07_lamp.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (1MB) | Request a copy

Abstract

Artificial lifting is a method used to enhance oil production from wells that are unable to naturally flow fluids to the surface. Various types of artificial lift, such as Sucker Rod Pump (SRP) and Electric Submersible Pump (ESP), are selected based on well characteristics and production requirements. The conversion is driven by mechanical limitations and frequent failures of the SRP system, as well as the opportunity to enhance production efficiency. Technical analysis was conducted using the Inflow Performance Relationship (IPR) curve approach with the Vogel method, along with calculations of Pump Intake Pressure (PIP), Total Dynamic Head (TDH), and a comprehensive ESP system design including pump stage selection, motor sizing, cable specification, and gas separator configuration. The results demonstrate that the conversion improves the fluid flow rate from 372 BFPD to an optimal rate of 456 BFPD, and increases oil production from 19 BOPD to 37 BOPD. With a calculated TDH of 1,731.9 ft and a maximum fluid production capacity of 570 BFPD, the study concludes that implementing ESP at well RAA137 is technically feasible and offers a significant improvement in production efficiency. These findings provide valuable insights for optimizing production strategies in mature oil fields.

Item Type:	Thesis (Undergraduate)
Uncontrolled Keywords:	Electrical Submersible Pump, IPR, Vogel, Optimasi Produksi Sumur
Subjects:	T Technology > TN Mining engineering. Metallurgy > TN1-997 Mining engineering. Metallurgy
Divisions:	03-Faculty of Engineering > 31201-Mining Engineering (S1)
Depositing User:	Muhammad Rasyidin
Date Deposited:	25 Jul 2025 07:12
Last Modified:	25 Jul 2025 07:14
URI:	http://repository.unsri.ac.id/id/eprint/180490
