ANALISIS PERILAKU SAMBUNGAN BALOK-KOLOM EKSTERIOR CRUMB RUBBER CONCRETE DENGAN VARIASI TULANGAN GESER TERHADAP BEBAN LATERAL SIKLIK

PRASETIYA, MUHAMMAD ANGGARA ADJI and Usman, Arie Putra and Nurjannah, Siti Aisyah (2025) ANALISIS PERILAKU SAMBUNGAN BALOK-KOLOM EKSTERIOR CRUMB RUBBER CONCRETE DENGAN VARIASI TULANGAN GESER TERHADAP BEBAN LATERAL SIKLIK. Masters thesis, Sriwijaya University.

	Image RAMA_22101_03022682327019_cover.jpeg - Accepted Version Available under License Creative Commons Public Domain Dedication. Download (476kB)
	Text RAMA_22101_03022682327019_TURNITIN.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (24MB) | Request a copy
	Text RAMA_22101_03022682327019.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (11MB) | Request a copy
	Text RAMA_22101_03022682327019_0019058605_8884960018_01_front_ref.pdf - Accepted Version Available under License Creative Commons Public Domain Dedication. Download (1MB)
	Text RAMA_22101_03022682327019_0019058605_8884960018_02.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (1MB) | Request a copy
	Text RAMA_22101_03022682327019_0019058605_8884960018_03.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (1MB) | Request a copy
	Text RAMA_22101_03022682327019_0019058605_8884960018_04.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (2MB) | Request a copy
	Text RAMA_22101_03022682327019_0019058605_8884960018_05.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (244kB) | Request a copy
	Text RAMA_22101_03022682327019_0019058605_8884960018_06_ref.pdf - Bibliography Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (225kB) | Request a copy
	Text RAMA_22101_03022682327019_0019058605_8884960018_07_lamp.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (4MB) | Request a copy

Abstract

This study aims to analyze the behavior of exterior beam–column joints made of crumb rubber concrete (CRC), which incorporates partial substitution of fine aggregate, under cyclic lateral loading with variations in shear reinforcement. The background of this research is based on the high seismic risk in Indonesia and the critical role of beam–column joints in earthquake-resistant structures. Additionally, the utilization of waste tires in the form of crumb rubber offers a sustainable construction solution, although it faces a reduction in compressive strength due to the weak bond between rubber particles and cement paste. This issue is addressed through an aqua-thermal treatment process (washing and heating). The research methodology includes laboratory testing to obtain the mechanical properties of CRC and numerical simulation using ANSYS to evaluate the structural behavior of exterior beam–column joints under cyclic lateral loads. CRC with a 5% crumb rubber substitution achieved an optimal compressive strength of 34.25 MPa and a splitting tensile strength of 2.74 MPa. Meanwhile, 10% CRC showed an increased elastic modulus of up to 12,842 MPa and a Poisson’s ratio of 0.230, indicating enhanced ductility. The deviation in lateral load between simulation and experimental results was within 8–9%, which is acceptable under the ≤10% tolerance limit. Variations in shear reinforcement spacing within the joint zone included Ø10–80 mm, Ø10–60 mm, Ø10–48 mm, and Ø10–40 mm. The analysis results indicate that closer stirrup spacing leads to higher stiffness and lateral load capacity of the joint due to increased confinement effects on the concrete. Nevertheless, the highest ductility value of 2.914 was observed in the model with the widest stirrup spacing (Ø10–80 mm). All models fall under the category of moderate ductility (2–4) by FEMA 356 (2000) criteria. Keywords: Exterior beam–column joint, crumb rubber concrete, finite element method, cyclic lateral load, shear reinforcement.

Item Type:	Thesis (Masters)
Uncontrolled Keywords:	Sambungan balok-kolom eksterior, crumb rubber concrete, finite element method, beban lateral siklik, tulangan geser
Subjects:	T Technology > TA Engineering (General). Civil engineering (General) > TA329-348 Engineering mathematics. Engineering analysis > TA347.F5C4665 Finite Element Method, Computer System Engineering Mathematics, T Technology > TA Engineering (General). Civil engineering (General) > TA401-492 Materials of engineering and construction. Mechanics of materials > TA418.38.I48 Materials--Fatigue--Congresses. Materials--Corrosion fatigue--Congresses T Technology > TA Engineering (General). Civil engineering (General) > TA401-492 Materials of engineering and construction. Mechanics of materials > TA418.9.C6.B538 Composite materials. Polymeric composites. Fibrous composites. Biomass chemicals. TECHNOLOGY & ENGINEERING / Material Science. SCIENCE / Chemistry / General T Technology > TA Engineering (General). Civil engineering (General) > TA630-695 Structural engineering (General) > TA647.H356 Structural dynamics-Vibration-Shock (Mechanics)- Airframes--Testing Buildings--Earthquake effects--Data processing--Handbooks, manuals, etc
Divisions:	03-Faculty of Engineering > 22101-Civil Engineering (S2)
Depositing User:	Muhammad Anggara Adji Prasetiya
Date Deposited:	25 Aug 2025 08:46
Last Modified:	25 Aug 2025 08:46
URI:	http://repository.unsri.ac.id/id/eprint/183244
