ANALISIS PERBANDINGAN BAHAN AKRILIK DENGAN POLIKARBONAT SEBAGAI PELINDUNG PANEL SURYA TERHADAP DAYA KELUARAN PADA PHOTOVOLTAIC JENIS MONOCRYSTALLINE 50 WP

AL HAFIZ, MUHAMMAD AULIA and Caroline, Caroline (2025) ANALISIS PERBANDINGAN BAHAN AKRILIK DENGAN POLIKARBONAT SEBAGAI PELINDUNG PANEL SURYA TERHADAP DAYA KELUARAN PADA PHOTOVOLTAIC JENIS MONOCRYSTALLINE 50 WP. Undergraduate thesis, Sriwijaya University.

Preview	Image RAMA_20201_03041282126039_cover.jpg - Accepted Version Available under License Creative Commons Public Domain Dedication. Download (342kB) | Preview
	Text RAMA_20201_03041282126039.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (6MB) | Request a copy
	Text RAMA_20201_03041282126039_TURNITI.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (4MB) | Request a copy
	Text RAMA_20201_03041282126039_0025017706_01_front_ref.pdf - Accepted Version Available under License Creative Commons Public Domain Dedication. Download (847kB)
	Text RAMA_20201_03041282126039_0025017706_02.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (449kB) | Request a copy
	Text RAMA_20201_03041282126039_0025017706_03.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (525kB) | Request a copy
	Text RAMA_20201_03041282126039_0025017706_04.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (837kB) | Request a copy
	Text RAMA_20201_03041282126039_0025017706_05.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (181kB) | Request a copy
	Text RAMA_20201_03041282126039_0025017706_06_ref.pdf - Bibliography Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (185kB) | Request a copy
	Text RAMA_20201_03041282126039_0025017706_07_lamp.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (4MB) | Request a copy

Abstract

Solar energy is a promising renewable energy source in Indonesia, but its performance is influenced by factors such as temperature, light intensity, and panel cleanliness. This study compares the effectiveness of acrylic and polycarbonate as protective covers for 50 Wp monocrystalline solar panels. Tests were conducted over 10 days under three conditions: without cover (PV1), with polycarbonate cover (PV2), and with acrylic cover (PV3), measuring voltage, current, surface temperature, and power output. The results show that PV3 produced the highest average power at 9.43 W, followed by PV1 at 8.05 W, and PV2 at 7.29 W. Despite higher temperatures, PV3 performed better due to acrylic’s high light transmission (90–92%), resulting in greater current and power. In contrast, polycarbonate reduced performance due to lower light transmission and higher temperatures. Thus, acrylic is more effective in enhancing power output while providing physical protection compared to polycarbonate or no cover.

Item Type:	Thesis (Undergraduate)
Uncontrolled Keywords:	Panel surya, Akrilik, Polikarbonat, Daya Keluaran, Fotovoltaik, Monokristalin.
Subjects:	T Technology > TK Electrical engineering. Electronics Nuclear engineering > TK1001-1841 Production of electric energy or power. Powerplants. Central stations > TK1087.A374 Building-integrated photovoltaic systems T Technology > TK Electrical engineering. Electronics Nuclear engineering > TK1001-1841 Production of electric energy or power. Powerplants. Central stations > TK1087.B344 Photovoltaic power systems T Technology > TK Electrical engineering. Electronics Nuclear engineering > TK2896-2985 Production of electricity by direct energy conversion > TK2960.R35 Solar batteries. Photovoltaic power generation. T Technology > TK Electrical engineering. Electronics Nuclear engineering > TK452-454.4 Electric apparatus and materials. Electric circuits. Electric networks
Divisions:	03-Faculty of Engineering > 20201-Electrical Engineering (S1)
Depositing User:	Muhammad Aulia Al Hafiz
Date Deposited:	05 Jun 2025 01:24
Last Modified:	05 Jun 2025 01:24
URI:	http://repository.unsri.ac.id/id/eprint/175171
