SEGMENTASI LUBANG DAN RUANG JANTUNG ANAK NON DOPPLER MELALUI PERANGKAT MOBILE MENGGUNAKAN YOU ONLY LOOK ONCE (YOLO)

ANDINI, MUTIAH and Nurmaini, Siti (2025) SEGMENTASI LUBANG DAN RUANG JANTUNG ANAK NON DOPPLER MELALUI PERANGKAT MOBILE MENGGUNAKAN YOU ONLY LOOK ONCE (YOLO). Undergraduate thesis, Sriwijaya University.

Preview	Image RAMA_56201_09011182126027_cover.jpg - Cover Image Available under License Creative Commons Public Domain Dedication. Download (751kB) | Preview
	Text RAMA_56201_09011182126027.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (7MB) | Request a copy
	Text RAMA_56201_09011182126027_TURNITIN.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (11MB) | Request a copy
	Text RAMA_56201_09011182126027_0002085908_01_front_ref.pdf - Accepted Version Available under License Creative Commons Public Domain Dedication. Download (981kB)
	Text RAMA_56201_09011182126027_0002085908_02.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (658kB) | Request a copy
	Text RAMA_56201_09011182126027_0002085908_03.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (989kB) | Request a copy
	Text RAMA_56201_09011182126027_0002085908_04.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (4MB) | Request a copy
	Text RAMA_56201_09011182126027_0002085908_05.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (251kB) | Request a copy
	Text RAMA_56201_09011182126027_0002085908_06_ref.pdf - Bibliography Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (235kB) | Request a copy
	Text RAMA_56201_09011182126027_0002085908_07_lamp.pdf - Accepted Version Restricted to Repository staff only Available under License Creative Commons Public Domain Dedication. Download (1MB) | Request a copy

Abstract

Non-Doppler segmentation of pediatric heart holes and chambers using deep learning approach with You Only Look Once (YOLO) algorithm through mobile devices. The main objective of this study is to evaluate the performance of YOLOv8 in segmenting cardiac structures, namely chambers and orifices, such as the right atrium, left atrium, right ventricle, left ventricle, and heart pit, from non-Doppler ultrasound images based on five main views: Four-chamber (4CH), Five-chamber (5CH), Long Axis (LA), Short Axis (SA), and Subcostal (SUB). Evaluation using mAP50 and IoU metrics on validation and unseen data showed that the best model, YOLOv8l with 200 epochs and batch size 4, achieved the highest segmentation performance on the 4CH view (mAP50: 0. 851, IoU: 0.709), 5CH (mAP50: 0.876, IoU: 0.763), LA (mAP50: 0.905, IoU: 0.754), SA (mAP50: 0.850, IoU: 0.724), and SUB (mAP50: 0.720, IoU: 0.697). Comparison with the raw data shows higher IoU performance, which is 0.787 in 4CH view, 0.798 in 5CH view, 0.802 in LA view, 0.829 in SA view as the best value, and 0.806 in SUB view. These results show that the implementation of YOLOv8 via mobile devices is quite good, even though the raw data shows superior segmentation performance.

Item Type:	Thesis (Undergraduate)
Uncontrolled Keywords:	Segmentasi Citra, Jantung Anak, Deep Learning, YOLOv8, Ultrasonografi Non-Doppler, Perangkat Mobile.
Subjects:	Q Science > Q Science (General) > Q334-342 Computer science. Artificial intelligence. Algorithms. Robotics. Automation.
Divisions:	09-Faculty of Computer Science > 56201-Computer Systems (S1)
Depositing User:	Mutiah Andini
Date Deposited:	11 Jul 2025 08:09
Last Modified:	11 Jul 2025 08:09
URI:	http://repository.unsri.ac.id/id/eprint/177898
